Overview

Development of a comprehensive 3D BIM model for an active industrial facility, capturing the density of MEP (Mechanical, Electrical, and Plumbing) systems. Detailed modeling of the building's heavy-duty industrial envelope, including trusses, gantries, and reinforced structural members. Accurate representation of large-scale mechanical equipment and high-pressure piping networks integrated within the architectural shell.

Project info

  • Architect : Ratan
  • Client : Centrale Emile Huet
  • Terms : 6 month
  • Project Type : Structural
  • Strategy : Industrial Heritage Scan-to-BIM
  • Date : September 2, 2025

Design in Details

Project Scope & Objectives
  • Industrial Digital Twin: Development of a comprehensive 3D BIM model for an active industrial facility, capturing the density of MEP (Mechanical, Electrical, and Plumbing) systems.
  • Structural Precision: Detailed modeling of the building’s heavy-duty industrial envelope, including trusses, gantries, and reinforced structural members.
  • Infrastructure Mapping: Accurate representation of large-scale mechanical equipment and high-pressure piping networks integrated within the architectural shell.
Technical Deliverables
  • High-Fidelity Revit Model: A coordinated as-built model reflecting the current physical state of the facility across multiple zones.
  • MEP & Structural Coordination: Identification and modeling of complex intersections between architectural elements and industrial machinery.
  • Zonal Analysis: Modular modeling of specific zones (Zones 3–7) to facilitate targeted maintenance and operational planning.
Project Specifications:
  • Industry: Industrial / Power Generation
  • Project Type: Scan-to-BIM & As-Built Documentation.
  • Key Inputs: 3D Laser Scan Data (Point Cloud).
  • Deliverables: Detailed Revit (RVT) BIM Model.
  • LOD: LOD 300+ (Mechanical & Structural focus).
  • Software: Autodesk Revit, Navisworks, Recap.
